Eco-Mesh

Welded Wire Mesh Solutions

Overview

Eco-Mesh is an economical, versatile welded wire mesh system—perfectly adaptable across agricultural, transport, industrial, sporting and decorative applications. It’s engineered to deliver durability, corrosion resistance and visual transparency without compromising on strength.

Materials & Surface Treatments

Mild Steel / Galvanised Steel Wire – Dipped in molten zinc post-weld to ensure full rust resistance, including at weld joints. Anticlimb
PVC-Coated Mesh – Features a flexible, heat-bonded PVC layer that prevents cracking during bending, sealing the mesh from moisture and corrosive elements, with underlying zinc providing added protection.
Stainless Steel Mesh – Naturally corrosion-resistant and robust, requiring no additional coatings for long-term performance.

Key Features

Exceptional Corrosion & Oxidation Resistance – Maintains integrity even in extreme hot or cold environments.
Scrape-Resistant Coating – Engineered to endure abrasion and rough handling.
Customisable Specifications – Available in a wide variety of mesh openings and wire gauges to suit specific project needs.

Standard Specifications

Mesh Opening (inches)	Approx. Metric (mm)	Wire Gauge Options (BWG)
¼″ × ¼″	6.4 mm × 6.4 mm	22, 23, 24
⅜″ × ⅜″	9.5 mm × 9.5 mm	19–22
½″ × ½″	12.7 mm × 12.7 mm	16–23
⅝″ × ⅝″	16 mm × 16 mm	18–21
¾″ × ¾″	19 mm × 19 mm	16–21
1″ × ½″	25.4 mm × 12.7 mm	16–21
1½″ × 1½″	38 mm × 38 mm	14–21
1″ × 2″	25.4 mm × 50.8 mm	14–16
2″ × 2″	50.8 mm × 50.8 mm	12–16
2″ × 3″	50 mm × 75 mm	Multiple (e.g., 2.0 mm, 2.5 mm, 1.65 mm)
3″ × 3″	75 mm × 75 mm	Varying (1.65–2.67 mm)
2″ × 4″	50 mm × 100 mm	2.11 mm, 2.5 mm
4″ × 4″	100 mm × 100 mm	2.0 mm, 2.5 mm

Special dimensions and gauges are available on request.

Applications

Eco-Mesh is a highly flexible solution suitable for:

Agricultural and Livestock Enclosures – Ideal for small animal cages and farm fencing.
Industrial & Machinery Protection – Durable guard mesh for equipment safety.
Transportation & Mining – Protective barriers that remain resilient in demanding environments.
Sports Fields & Landscaping – Secure and unobtrusive enclosures for recreational areas and decorative uses.

Key Benefits of Eco-Mesh

Durable & Long-Lasting

Hot-dip galvanised core and optional PVC or stainless coating resist rust, wear and harsh weather conditions.

Customisable Design

Mesh openings, wire gauges, heights and widths can be tailored to your project’s unique requirements.

Cost-Effective Solution

Provides high performance at a competitive price, making it ideal for large-scale and repeated installations.
